| ITEM | UNIT | KH250 | KH300 | KH400 |
|---|---|---|---|---|
| Hammer weight | kg | 1600 | 1800 | 1900 |
| Extension boom weight | kg | 600 | 700 | 700 |
| Hydraulic oil flow | lpm | 130 ∼ 180 | 170 ∼ 200 | 200 ∼ 260 |
| Operating pressure | bar | 180 ∼ 200 | 200 ∼ 250 | 200 ∼ 250 |
| Clamping Jaw | mm | 65 | 65 | 65 |
| Frequency | bpm | 2000 ∼ 2500 | 2000 ∼ 2500 | 2000 ∼ 2500 |
| Slewing degree | º | 360 | 360 | 360 |
| Dimension (LxWxH) | mm | 1857x1042x650 | 1959x1103x792 | 2016x1196x830 |
| Carrier range | ton | 20 ∼ 28 | 28 ∼ 34 | 33 ∼ 40 |
